10L ikojọpọ ẹrọ mulring

Model:KGB70A

Kgbb70a jẹ ohun elo 10L royin ẹrọ ẹrọ fẹu ti a ṣe apẹrẹ fun igo 15-lita fẹ kalẹ. Bi olupese ẹrọ igo omi igo, a nfun awọn solusan adayewo lati pade awọn ibeere alabara. Ẹrọ naa kii ṣe fun awọn igo omi nikan, awọn apoti ipanilaya, iṣelọpọ kemikali ojoojumọ ati fun awọn ọja apẹrẹ kekere ṣugbọn pataki. Ẹrọ yii wa awọn aini oriṣiriṣi.

Iwọn didun: 20LIwuwo: 7.8T

Fi ibeere ranṣẹ

ọja Apejuwe Specification Application

Kgbb70a 10L ṣowo Ẹrọ Culdring jẹ ṣiṣi ṣiṣi ati pipade Awoṣe, eyiti o mu ilọpo double fa ẹrọ ti o ni nkan mimu nkan mimu, epo Silinda taara titẹ bọtini titiipa m Iṣakoso Eto Hydralic Serve, iyara esi ti iyara ati fifipamọ agbara.
Diẹ sii Suite fun apẹrẹ ọja apẹrẹ apẹrẹ pataki ti a ṣe, le Ṣe iṣakoso apẹrẹ ati sisanra diẹ sii deede.

Awọn ẹya ati awọn anfani

Awoṣe yii jẹ ṣiṣi ti o wa titi ati pipade pipade, ni lilo Triid Fiimu Kan
● Cylinder ibi-itọju ku lẹsẹsẹ
● Iwọn didun ti o pọju 20L
O dara fun awọn igo omi, awọn apoti ipanilaya, ati apoti kemikali ojoojumọ, bbl.
● Eto iyasọtọ ni pe o jẹ iṣakoso nipasẹ eto iṣẹ hucrolic kan lati ṣaṣeyọri esi iṣẹ iyara ati ṣiṣe agbara giga.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
